Element: left-divider

Description

Dividers on the left and right side of the page are controlled by the left-divider and right-divider elements respectively.

Derived By

Type empty-print-object-style-align

Attributes
Name  Type  Required?  Default  Description
print-object  yes-no  No
default-x  tenths  No
default-y  tenths  No
relative-x  tenths  No
relative-y  tenths  No
font-family  comma-separated-text  No
font-style  font-style  No
font-size  font-size  No
font-weight  font-weight  No
color  color  No
halign  left-center-right  No
valign  valign  No  The valign attribute is used to indicate vertical alignment to the top, middle, bottom, or baseline of the text or image. Defaults are implementation-dependent.
Content Model

Always empty.

Referenced By
Example

    <system-layout>
      <system-margins>
        <left-margin>0</left-margin>
        <right-margin>0</right-margin>
      </system-margins>
      <system-distance>96</system-distance>
      <top-system-distance>45</top-system-distance>
      <system-dividers>
        <left-divider print-object="yes"/>
        <right-divider print-object="yes"/>
      </system-dividers>
    </system-layout>

Definition

See system-dividers
