Element: credit-image


The credit-image element is similar to the image elements for directions. However, since the credit is not part of a measure, the default-x and default-y attributes adjust the origin relative to the bottom left-hand corner of the first page. The enclosure for credit-words is none by default.

Derived By

Type image

Name  Type  Required?  Default  Description
source  xs:anyURI  Yes
type  xs:token  Yes
default-x  tenths  No
default-y  tenths  No
relative-x  tenths  No
relative-y  tenths  No
halign  left-center-right  No
valign  valign-image  No  The valign attribute is used to indicate vertical alignment to the top, middle, bottom, or baseline of the text or image. Defaults are implementation-dependent.
Content Model

Always empty.

Referenced By

  <credit page="1">
    <credit-image source=”images/mmlogo.png” type="image.png" default-x="572" default-y="96"/>


See credit
