Element: measure-numbering

Description

The measure-numbering type describes how frequently measure numbers are displayed on this part. The number attribute from the measure element is used for printing. Measures with an implicit attribute set to "yes" never display a measure number, regardless of the measure-numbering setting.

Derived By

Type measure-numbering

Attributes
Name  Type  Required?  Default  Description
default-x  tenths  No
default-y  tenths  No
relative-x  tenths  No
relative-y  tenths  No
font-family  comma-separated-text  No
font-style  font-style  No
font-size  font-size  No
font-weight  font-weight  No
color  color  No
halign  left-center-right  No
valign  valign  No  The valign attribute is used to indicate vertical alignment to the top, middle, bottom, or baseline of the text or image. Defaults are implementation-dependent.
Content Model

Contains text only.

Referenced By
Example

      <print>
        <system-layout>
          <system-margins>
            <left-margin>58</left-margin>
            <right-margin>0</right-margin>
          </system-margins>
          <top-system-distance>113</top-system-distance>
        </system-layout>
        <measure-numbering>system</measure-numbering>
      </print>

Definition

See print
